41
MODEL NUMBER
MAX GPM MAX PSI
MAX RPM
PORT SIZE
9910-D30
9.6
580
550
1" HB inlet, 1/2" HB outlet
9910-D30GRGI
9.6
580
3600
Assembled with gearbox 9910-KIT1640 and control
9910-GS40GI for mounting on 5 hp gas engine
MODEL NUMBER
MAX GPM MAX PSI
MAX RPM
PORT SIZE
9910-D403
9.9
580
550
1" HB inlet, 1/2" HB outlet
9910-D403GRGI
9.9
580
3600
Assembled with gearbox 9910-KIT1640 and control 9910-
GR40 for mounting on 5 - 6 hp gas engine
MEDIUM PRESSURE D30
MEDIUM PRESSURE D403
• Max. fluid temperature: 140° F
• Shaft: flanged for shaft kit (D30); ¾” hollow shaft for gas engine
mount (D30GRGI)
• Diaphragms: 2, semi-hydraulic Desmopan
• Housing components epoxy-coated for liquid handling
• Recommended control unit: 9910-GS40GI
• Weight: 23 lbs.
• Max. fluid temperature: 140° F
• Shaft: flanged for kit attachment (D403); ¾” hollow shaft for gas
engine mount (D403GRGI)
• Diaphragms: 3, semi-hydraulic Desmopan
• Housing: Anodized aluminum
• Mounting base included
• Recommended control unit: 9910-GR40
• Weight: 23 lbs.
HYPRO DIAPHRAGM PUMPS
