CONTROL UNITS
A
B
C
D
E
REF #
MODEL
FOR PUMP
MODEL
INCLUDES
MAX FLOW
MAX
PRESSURE
WEIGHT
A
9910-GS40GI
D30 & D50 One pressure gauge, one adjustable high pressure
relief valve, one complete bypass lever, two 1/2"
HB outlets with individual shut-offs, and one 3/4"
HB bypass. Kit 9910-KIT1741 is available for remote
mounting.
21 gpm 580 psi
3.5 lbs
B
9910-GR40
D403
One pressure gauge, adjustable high pressure
relief valve, complete bypass lever, 2-1/2" pressure
gauge, two 1/2" HB outlets with individual shut-offs
and one 5/8" HB bypass. Kit 9910-KIT1741 is avail-
able for remote mounting.
11 gpm 580 psi
2 lbs
C
9910-RM40
D503
One pressure gauge, one adjustable high pressure
relief valve, one complete bypass knob, two 1/2"
HB outlets with individual shut-offs, and one 1" HB
bypass. Kit 9910-KIT1897 is available for remote
mounting.
24 gpm 580 psi
3.5 lbs
D
3300-0088
LTA
One built-in relief valve, one 1" HB inlet, three 3/4",
1/2" and 3/8" HB outlets with individual shut-offs.
Model 3300-0088 also includes a main bypass lever
42.5 gpm 290 psi
7.75 lbs
E
SB-3
LTA
Remote-mounted control valve provides three, four,
five or six section spray boom control & a master
on-off lever. Has 3/4" hose barb inlet, 1" hose barb
bypass, 1/2" hose barb outlet ports & 1/4" female
NPT gauge port. Optional 3/4" hose barb outlet
ports are also available (Part #1406.26).
35 gpm 300 psi
