46 / 60
I N D U S T R I A L S E R V I C E S C OM PA N Y
|
P
7 4 0 . 9 6 5 . 4 1 1 2
F
7 4 0 . 9 6 5 . 5 3 2 4
46
Z-SPRAY PARTS
Z-SPRAY NOZZLES
Z-SPRAY REPLACEMENT PUMP
TIP COLOR
PART NO.
MPH
PRESSURE (PSI)
GAL / 1000 SQ. FT.
Yellow
AVI-11002
5
40
1/4 gal
Lavender
AVI-110025
5
40
1/3 gal
Red
AVI-11004
5
40
1/2 gal
Brown
AVI-11005
5
50
3/4 gal
Grey
AVI-11006
4
40
1 gal
MODEL NUMBER
MAX PSI
MAX GPM
MAX DRAW
7970-111Y
100
7
25 Amps
• Excellent drift reduction
• Large passages resist plugging
• Wear-resistant Albuz® ceramic orifice
• Pressures from 30 to 100 psi
• Available as standard tip and as convenient FastCap® for
safer handling
The Albuz
®
AVI draws air into the tip and mixes it with the spray to
create very coarse droplets that minimize spray drift. The air-filled
droplets have a larger footprint on the leaf than similar non-air
droplets and hold to the leaf for better control. Durable Albuz
®
ceramic orifice creates the longest wearing spray tip of its kind.
• 12-volt DC motor drive
• Leads: 12 AWG, 12” long
• Housing: Polypropylene
• Port sizes: ¾” Delavan Quick Attach
• Fasteners: Stainless Steel
• Diaphragms: Santoprene
